Image Sensor | 1/2.5" Progressive Scan CMOS |
---|---|
Max. Resolution | 2560 × 1920 |
Min. Illumination | Color: 0.01Lux @ (F1.2, AGC ON), 0.034Lux @ (F2.2, AGC ON), 0 Lux with IR on |
Shutter Speed | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter with auto switch |
Focal Length & FOV | 1.05 mm, horizontal field of view: 180°, vertical field of view: 180° |
Lens Mount | M12 |
Aperture | F2.2 |
Main Stream | 50Hz: 25fps (2560 × 1920, 2048 × 1536, 1280 × 960),60Hz: 30fps (2560 × 1920, 2048 × 1536, 1280 × 960), |
Sub-Stream | 50Hz: 25fps (352× 288, 704 × 576),60Hz: 30fps (352 × 240, 704 × 576), |
Video Compression | Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEG |
Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
API | ONVIF (PROFILE S, PROFILE G), ISAPI |
Wide Dynamic Range (WDR) | 120 dB |
Day/Night Switch | Auto/Schedule/Triggered by Alarm In (-S model supports) |
Audio | -S: 1 audio input (line in), 1 audio output interface |
Image Enhancement | WDR/3D DNR/Backlight Compensation/Defog/Distortion Correction |
Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
Basic Event | Motion detection, dynamic analysis, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
Smart Event | Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection |
Power | DC 12V ± 25%, 2A, 5W,PoE(802.3af 36-57V, class 3), 0.4 – 0.7 A, 6.7W, |
Dimension | Φ 119.9 × 41.2 mm (Φ 4.72″ × 1.62″) |
Startup And Operating Conditions | -10 °C to +50 °C (-14 °F to +122 °F). Humidity 95% or less (non-condensing) |
