Hikvision 6MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera DS-2CD2T67G2H-LISU/SL
Standart Camera
Image Sensor | 1/3" progressive scan CMOS |
---|---|
Max. Resolution | 2560 × 1440 |
Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 75° |
Day & Night | IR cut filter |
Focal Length & FOV | 2.8 mm, horizontal FOV 98.0°, vertical FOV 53.1°, diagonal FOV 114.7° 4 mm, horizontal FOV 78.7°, vertical FOV 43.1°, diagonal FOV 92.3° |
Aperture | F2.0 |
Supplement Light Range | Up to 30 m |
Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
Video Compression | Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG |
Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
Simultaneous Live View | Up to 6 channels |
API | Open Network Video Interface, ISAPI |
User/Host | Up to 32 users. 3 levels: administrator, operator and user |
Client | iVMS-4200, Hik-Connect |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
Wide Dynamic Range (WDR) | 120 dB |
Image Enhancement | BLC, 3D DNR |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | Built-in memory card slot, support microSD card, up to 256 GB |
Built-In Microphone | Yes |
Reset Key | Yes |
Basic Event | Motion detection, video tampering, exception |
Linkage | Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture |
Power | 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Dimension | Ø120 mm × 92.2 mm (4.72" × 3.63") |
Weight | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") Approx. 440 g (1.0 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Language | English, Ukrainian |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection | IP67 (IEC 60529-2013), IK10 (IEC 62262:2002 |
