Hikvision 8C Series 8MP 25X DarkFighter IR PTZ Network Speed Dome Camera DS-2DF8C825IXG-ELW ( Хөдөлгөөнт Хяналтын Камер )
Барааны код: #20046
Бүтээгдэхүүний үндсэн үзүүлэлт
- Брэнд: ViewSonic
Үнэ :
6,699,900 ₮
0 ширхэг бэлэн байна
Энэ бараа дууссан байна. Танд асуух зүйл байвал 7575-6677 утсаар холбогдоорой
Техникийн үзүүлэлт
| Image Sensor | 1/1.2" progressive scan CMOS |
| Max. Resolution | 3840 × 2160 (8 MP) |
| Min. Illumination | Color: 0.002 Lux @ (F1.6, AGC ON), B/W: 0.0002 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/1 s to 1/30,000 s |
| Slow Shutter | Yes |
| Day & Night | IR cut filter |
| Zoom | 25× optical, 16× digital |
| Focal Length | 7.5 mm to 187.5 mm, 25× optical |
| Zoom Speed | Approx. 6.8 s |
| FOV | Horizontal: 60.4° to 3.7°; vertical: 36.2° to 2.1°; diagonal: 67.8° to 4.3° (wide-tele) |
| Aperture | Max. F1.6 |
| Focus | Auto, semi-auto, manual, rapid focus |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 500 m |
| Smart Supplement Light | Yes |
| Movement Range (Pan) | 360°, smart pan-tilt correction |
| Movement Range (Tilt) | -20° to 90° (auto flip), smart pan-tilt correction |
| Pan Speed | Configurable from 0.1° to 210°/s; preset speed: 280°/s |
| Tilt Speed | Configurable from 0.1° to 150°/s; preset speed: 250°/s |
| Proportional Pan | Yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory | Yes |
| Park Action | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Preset Freezing | Yes |
| Scheduled Task | Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 24 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 24 fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288); 60 Hz: 24 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264; sub-stream: H.265/H.264/MJPEG; third stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16384 Kbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 8 fixed regions for each stream |
| Audio Compression | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM, AAC_LC |
| Day/Night Switch | Day, night, auto, scheduled-switch |
| Image Enhancement | BLC, HLC, 3D DNR |
| Wide Dynamic Range (WDR) | 140 dB |
| Defog | Optical defog |
| Image Stabilization | EIS (built-in gyroscope) |
| Regional Exposure | Yes |
| Regional Focus | Yes |
| Privacy Mask | Up to 24 masks, mosaic mask, mask color configurable, rectangle region |
| SNR | ≥ 52 dB |
| Basic Event | Motion detection, video tampering alarm, alarm input, alarm output, exception |
| Smart Event | Line crossing, region entrance, unattended baggage, object removal, intrusion, region exiting detection, vandal-proof alarm, audio exception detection |
| Smart Tracking | Manual tracking, auto-tracking |
| Face Capture | Detects up to 30 faces at the same time; detecting, tracking, capturing, grading, selecting of face in motion, outputs the best face picture |
| Face Comparison | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance, region exiting; alarm triggering by specified target types (human and vehicle) |
| Road Traffic | Vehicle detection (license plate number, vehicle model, and vehicle color recognition) |
| Alarm Linkage | Preset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, NAS video recording, audible warning |
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets |
| API | ISUP, ISAPI, Hikvision SDK, ONVIF (Profile S, Profile G, Profile T), OTAP |
| Simultaneous Live View | Up to 20 channels |
| User/Host | Up to 32 users; 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, digest authentication, RTP/RTSP over HTTPS, security audit log, TLS 1.3, host authentication (MAC address) |
| Client | HikCentral, iVMS-4200, Hik-Connect |
| Video Output | 1.0 V[p-p]/75 Ω, PAL, NTSC, BNC connector |
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board Storage | Built-in memory card slot, microSD/microSDHC/microSDXC, up to 256 GB |
| Alarm | 7 inputs, 2 outputs |
| Audio Interface | 1 input (line in), 1 output (line out) |
| RS-485 | Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power | 24 VAC (max. 62 W, including max. 12 W for IR and max. 8 W for heater); PoE 802.3bt (max. 51 W, including max. 12 W for IR and max. 8 W for heater) |
| Wiper | Yes, rain-sensing auto control |
| Operating Condition | Temperature: -40 °C to 70 °C (-40 °F to 158 °F); humidity: ≤ 95% |
| Dimension | Ø 267 × 430 mm (Ø 10.51" × 16.93") |
| Weight | Approx. 9.6 kg (21.16 lb.) |
